Satoh S630 Tractors

Satoh S630
Power: 25 hp
Date of manufacture :
1980 - 1984
Production
Manufacturer:Satoh
Type:Compact Utility tractor
Satoh S630 Power
Engine:25 hp
18.6 kW
PTO (claimed):22 hp
16.4 kW
Satoh S630 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:manual
Brakes:drum
Cab:Open operator station.
Transmission:9-speed gear
Hydraulics
Pump flow:3.49 gpm
13.2 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):1453 lbs
659 kg
Power Take-off (PTO)
Rear RPM:555/774/1025/1320 (1.375)
Dimensions & Tires
Wheelbase:60 inches
152 cm
Weight:2006 to 2138 pounds
Front tire:5.00-15
Rear tire:11.2-24 (2WD)
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
Battery AH:70
