Production |
Manufacturer: | Steyr
|
Mechanical |
Chassis: | 4x2 2WD
|
| 4x4 MFWD 4WD
|
Steering: | hydrostatic power
|
Brakes: | disc
|
| engine exhuast brake optional
|
Trailer brakes: | air brakes optional
|
Cab: | Steyr SK2 cab. Steyer Twin Cab optional. Reversible controls available.
|
Transmissions: | 18-speed synchronized
|
| 36-speed partial power shift
|
| 24-speed synchronized with creeper
|
| 48-speed partial power shift
|
Hydraulics |
Pressure: | 2,538 psi 175.0 bar
|
Valves: | 3
|
Total flow: | 10.8 gpm 40.9 lpm
|
Tractor hitch |
Rear lift: | 10,580 lbs 4799 kg
|
| 12,860 lbs 5833 kg (1987+)
|
Front lift: | 4,856 lbs 2202 kg
|
Power Take-off (PTO) |
Rear RPM: | 540/1000
|
Front RPM: | 1110
|
Dimensions & Tires |
Wheelbase: | 102.2 inches 259 cm
|
Weight: | 8576 to 9568 pounds
|
Front tire: | 9.00-16
|
Rear tire: | 16.9R34
|
