| Production |
| Manufacturer: | Steyr
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | disc
|
| | engine exhuast brake optional
|
| Trailer brakes: | air brakes optional
|
| Cab: | Steyr SK2 cab. Steyer Twin Cab optional. Reversible controls available.
|
| Transmissions: | 18-speed synchronized
|
| | 36-speed partial power shift
|
| | 24-speed synchronized with creeper
|
| | 48-speed partial power shift
|
| Hydraulics |
| Valves: | 3
|
| Total flow: | 10.8 gpm
40.9 lpm
|
| Tractor hitch |
| Rear lift: | 10,580 lbs
4799 kg
|
| | 12,860 lbs
5833 kg (1987+)
|
| Front lift: | 4,856 lbs
2202 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540/1000
|
| Front RPM: | 1110
|
| Dimensions & Tires |
| Wheelbase: | 102.2 inches
259 cm
|
| Weight: | 8774 to 9943 pounds
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4R34
|
| Full dimensions and tires ... | |
