| Production |
| Manufacturer: | Versatile
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Original price: | $94,000 (1984 )
|
| Versatile 835 Power |
| Engine: | 230 hp
171.5 kW
|
| PTO (claimed): | 198 hp
147.6 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | outboard planetary
|
| Steering: | articulated power
|
| Brakes: | hydraulic disc
|
| Cab: | Cab with air-conditioning.
|
| Transmission: | 12-speed gear
|
| Capacity |
| Fuel: | 185 gal
700.2 L
|
| Hydraulic system: | 21 gal
79.5 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 21 gal
79.5 L
|
| Pressure: | 2250 psi
155.1 bar
|
| Valves: | 4
|
| Pump flow: | 23.6 gpm
89.3 lpm
|
| Steering flow: | 26.1 gpm
98.8 lpm
|
| Tractor hitch |
| Rear Type: | 4N/3
|
| Power Take-off (PTO) |
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 130 inches
330 cm
|
| Weight: | 20,000 lbs
9072 kg
|
| Front tire: | 20.8x38
|
| Rear tire: | 20.8x38
|
| Full dimensions and tires ... |
| 835 Serial Numbers |
| Location: | Serial number plate on the cab door post.
|
| 1978: | 835 78 033000
|
| 1979: | 835 79 033601
|
| 1980: | 835 80 034201
|
| 1981: | 835 81 035001
|
| 1982: | 835 82 035602
|
| 1983: | 835 83 000001
|
| 1984: | 835 84 037575
|
| Final: | 835 84 038075
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 75
|
| Batteries: | 2
|
| Battery CCA: | 900
|
| Battery volts: | 12
|
| Battery Group: | 80
|
|
