| Production |
| Manufacturer: | Versatile
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Original price: | $106,000 (1993 )
|
| Versatile 946 Power |
| Engine: | 325 hp
242.4 kW
|
| PTO (claimed): | 286 hp
213.3 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | outboard planetary
|
| Steering: | articulated power
|
| Brakes: | hydraulic disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 12-speed constant mesh
|
| | 12-speed full power shift
|
| Capacity |
| Fuel: | 286 gal
1082.5 L
|
| Hydraulic system: | 15.3 gal
57.9 L
|
| Hydraulics |
| Type: | closed center load sensing*Steering pump is open center.
|
| Capacity: | 15.3 gal
57.9 L
|
| Pressure: | 2400 psi
165.5 bar
|
| Valves: | 4 to 5
|
| Pump flow: | 24.5 gpm
92.7 lpm
|
| Steering flow: | 26.1 gpm
98.8 lpm
|
| Steering press.: | 2300 psi
158.6 bar
|
| Tractor hitch |
| Rear Type: | IVN/III
|
| Control: | position control
|
| Rear lift (at 24"/610mm): | 13036 lbs
5913 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent*PTO available only with power shift transmission.
|
| Rear RPM: | 1000 (1.75)
|
| Dimensions & Tires |
| Wheelbase: | 130 inches
330 cm
|
| Weight: | 32500 lbs
14742 kg
|
| Front tire: | 24.5-32
|
| Rear tire: | 24.5-32
|
| Full dimensions and tires ... |
| 946 Serial Numbers |
| Location: | Serial number plate on the cab door post.
|
| 1989: | 946 89 D430119
|
| 1990: | 946 90 D450110
|
| 1991: | 946 91 D475066
|
| 1992: | 946 92 D485002
|
| 1993: | 946 93 D930045
|
| Final: | 946 93 D931121
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 90
|
| Batteries: | 4
|
| Battery CCA: | 625
|
| Battery volts: | 12
|
|
