| Production |
| Manufacturer: | Versatile
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Original price: | $149,000 (1984)
|
| Versatile 975 Power |
| Engine: | 360 hp
268.5 kW
|
| Mechanical |
| Chassis: | 4x4 4WD
|
| Steering: | articulated power
|
| Brakes: | hydraulic disc
|
| Cab: | Cab with heat and A/C
|
| Transmission: | 12-speed
|
| Capacity |
| Fuel: | 185 gal
700.2 L
|
| Hydraulic system: | 21 gal
79.5 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 21 gal
79.5 L
|
| Pressure: | 2250 psi
155.1 bar
|
| Valves: | 4
|
| Pump flow: | 23.6 gpm
89.3 lpm
|
| Steering flow: | 26.1 gpm
98.8 lpm
|
| Tractor hitch |
| Rear Type: | 4N/3
|
| Dimensions & Tires |
| Wheelbase: | 130 inches
330 cm
|
| Weight: | 24,150 lbs
10954 kg
|
| Front tire: | 24.5x32
|
| Rear tire: | 24.5x32
|
| Full dimensions and tires ... |
| 975 Serial Numbers |
| Location: | Serial number plate on the cab door post.
|
| 1983: | 975 83 232045
|
| 1984: | 975 84 184625
|
| Final: | 975 84 184725
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 90
|
|
