| Production |
| Manufacturer: | Branson
|
| Type: | Compact Utility tractor
|
| Factory: | Yangsu-ri, South Korea
|
| Branson 4720 Power |
| Engine: | 40 hp
29.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post ROPS.
|
| Transmission: | 12-speed
|
| Capacity |
| Fuel: | 11.1 gal
42.0 L
|
| Hydraulic system: | 9.7 gal
36.7 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9.7 gal
36.7 L
|
| Valves: | 0 to 2
|
| Pump flow: | 8.9 gpm
33.7 lpm
|
| Total flow: | 13.2 gpm
50.0 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift: | 2580 lbs
1170 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live*2-stage clutch
|
| Rear RPM: | 540, 1000
|
| Dimensions & Tires |
| Wheelbase: | 71 inches
180 cm
|
| Weight: | 3,883 lbs
1761 kg
|
| Front tire: | 8-18
|
| Rear tire: | 12.4-28
|
| Electrical |
| Ground: | negative
|
| Charging amps: | 45
|
| Battery volts: | 12
|
|
