Navigation: Home > Case > 1170

Case 1170 Tractors

Case 1170
Power: 135 hp[P]
Date of manufacture :
1970 - 1971
Production
Manufacturer:J.I. Case
Type:Row-Crop tractor
Factory:Racine, Wisconsin, USA
Total built:1816
Original price:$12,700 (1970 )
J.I. Case 1170 Power
Drawbar (claimed):110 hp
82.0 kW
PTO (claimed):122 hp
91.0 kW
Drawbar (tested):108.15 hp
80.6 kW
PTO (tested):121.93 hp
90.9 kW
J.I. Case 1170 Engine
Mechanical
Chassis:4x2 2WD
Steering:power
Brakes:hydraulic disc
Cab:Open operator station. Cab optional.
Transmissions:8-speed
 12-speed
Hydraulics
Valves:2
Pump flow:16 gpm
60.6 lpm
Tractor hitch
Rear Type:II
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540, 1000
Dimensions & Tires
Weight:12,000 lbs
5443 kg
Front tire:10.00-16
Rear tire:18.4-38
Full dimensions and tires ...
