| Production |
| Manufacturer: | J.I. Case
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $58,700 (1983 )
|
| J.I. Case 2390 Power |
| Drawbar (tested): | 137.72 hp
102.7 kW
|
| PTO (tested): | 160.72 hp
119.8 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Silent Guardian cab standard with air-conditioning. Four-post ROPS available.
|
| Transmission: | 12-speed partial power shift
|
| Photos |
| | J.I. Case 2390 photos... |
| Hydraulics |
| Type: | closed center
|
| Pressure: | 2200 psi
151.7 bar
|
| Valves: | 2 to 4
|
| Pump flow: | 27 gpm
102.2 lpm
|
| Steering flow: | 8 gpm
30.3 lpm
|
| Steering press.: | 2000 psi
137.9 bar
|
| Tractor hitch |
| Rear Type: | III
|
| Rear lift: | 8000 lbs
3628 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000 (1.375)
|
| Engine RPM: | 1000@2100
|
| Dimensions & Tires |
| Wheelbase: | 104 inches
264 cm
|
| Weight: | 14270 to 15590 pounds
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4-38
|
| 2390 Serial Numbers |
| Location: | Data plate on instrument panel
|
| 1978: | 8835443
|
| 1979: | 8840001
|
| 1980: | 9901001
|
| 1981: | 9910025
|
| 1982: | 9918830
|
| 1983: | 9924700
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| ROPS Charging amps: | 61
|
| Cab Charging amps: | 72
|
| Charging volts: | 12
|
|
