Power: 50 hp[P] Date of manufacture : 1958 - 1959
Production Manufacturer: J.I. Case Type: Standard-tread tractor Factory: Rock Island, Illinois, USA Total built: 370 Variants 510B: utility 511B: row-crop J.I. Case 510-B Power PTO (claimed): 45 hp 33.6 kW J.I. Case 510-B Engine Mechanical Chassis: 4x2 2WD Steering: manual Brakes: disc Cab: Open operator station. Transmissions: 4-speed gear   8-speed mechanical shuttle Photos J.I. Case 510-B photos... Capacity Fuel: 13.8 gal 52.2 L Hydraulic system: 3 gal 11.4 L Hydraulics Type: open center Capacity: 3 gal 11.4 L Pressure: 1200 psi 82.7 bar Tractor hitch Type: Case Eagle Hitch*Optional Power Take-off (PTO) Rear PTO: transmission Rear RPM: 540 (1.375) Engine RPM: 540@1925 Dimensions & Tires Wheelbase: 78.5 inches 199 cm Weight: 3825 lbs 1735 kg Front tire: 6.00-16 Rear tire: 11-28 510-B Serial Numbers Location: Serial number plate on instrument panel 1958: 6095001 1959: 6120001 how to read serial numbers... Belt Pulley Diameter: 9.25 inches 23 cm Width: 6.4 inches 16 cm RPM: 1360 Speed: 3290 ft/min 1002.79 meters/min Electrical Ground: positive Battery volts: 12 Battery AH: 50
