| Production |
| Manufacturer: | J.I. Case
|
| Type: | Utility tractor
|
| Factories: | Racine, Wisconsin, USA
|
| | Rock Island, Illinois, USA
|
| Original price: | $5,700 (1969 )
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | power
|
| Brakes: | mechanical disc
|
| Cab: | Open operator station.
|
| Transmissions: | 12-speed
|
| | 8-speed torque converter
|
| | 4-speed gear
|
| | 8-speed mechanical shuttle
|
| Photos |
| | J.I. Case 530 photos... |
| Tractor hitch |
| Rear Type: | I
|
| Control: | position and depth control
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| | independent*Optional
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 81.5 inches
207 cm
|
| Weight: | 4000 lbs
1814 kg
|
| Front tire: | 5.50-16
|
| Rear tire: | 12.4-28
|
| Full dimensions and tires ... |
| 530 Serial Numbers |
| Location: | Serial number plate on tractor instrument panel.
|
| 1960: | 6144001
|
| 1961: | 6162601
|
| 1962: | 8190001
|
| 1963: | 8208001
|
| 1964: | 8229001
|
| 1965: | 8253501
|
| 1966: | 8279001
|
| 1967: | 8306501
|
| 1968: | 8332101
|
| 1969: | 8356251
|
how to read serial numbers...
| |
