| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Factory: | Doncaster, England
|
| Original price: | $14,000 (1990 )
|
| CaseIH 385 Power |
| Engine: | 43 hp
32.1 kW
|
| PTO (claimed): | 35 hp
26.1 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post ROPS. Optional canopy. Optional deluxe canopy with lights and radio wiring.
|
| Transmissions: | 8-speed synchromesh
|
| | 16-speed partial power shift
|
| | 8-speed power shuttle
|
| Photos |
| | CaseIH 385 photos... |
| Capacity |
| Fuel: | 20 gal
75.7 L
|
| Hydraulic system: | 9 gal
34.1 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9 gal
34.1 L
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 0 to 2
|
| Total flow: | 14.3 gpm
54.1 lpm
|
| Steering flow: | 2.5 gpm
9.5 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift (at 24"/610mm): | 2,158 lbs
978 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 79.6 inches
202 cm
|
| Weight: | 4869 to 5940 pounds
|
| Front tire: | 6.00-16
|
| Rear tire: | 13.6-28
|
| Full dimensions and tires ... |
| 385 Serial Numbers |
| Location: | Front right bolster
|
| 1985: | 15000
|
| 1986: | 18000
|
| 1987: | 18806
|
| 1988: | 19454
|
| 1989: | 20811
|
| 1990: | 22231
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 45
|
| Battery volts: | 12
|
| Battery AH: | 93
|
|
