| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Factory: | Doncaster, England
|
| Original price: | $16,000 (1990)
|
| Variants |
| 485: | utility
|
| 485-O: | orchard
|
| CaseIH 485 Power |
| Engine: | 53 hp
39.5 kW
|
| Drawbar (claimed): | 36.7 hp
27.4 kW
|
| PTO (claimed): | 43 hp
32.1 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Cab: | Two-post ROPS.
|
| Transmissions: | 8-speed synchromesh
|
| | 16-speed partial power shift
|
| Photos |
| | CaseIH 485 photos... |
| Capacity |
| Fuel: | 20 gal
75.7 L
|
| Hydraulic system: | 9 gal
34.1 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9 gal
34.1 L
|
| Valves: | 1 or 2
|
| Pump flow: | 15.9 gpm
60.2 lpm
|
| | 17 gpm
64.3 lpm (optional)
|
| Tractor hitch |
| Rear Type: | I,II
|
| Rear lift: | 2,338 lbs
1060 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 79.6 inches
202 cm
|
| Weight: | 5,200 lbs
2358 kg
|
| Front tire: | 6.00-16
|
| Rear tire: | 13.6-28
|
| Full dimensions and tires ... |
| 485 Serial Numbers |
| Location: | Near front axle on right.
|
photo of 485 serial number
| | 1985: | 15000
|
| 1986: | 18000
|
| 1987: | 19057
|
| 1988: | 21250
|
| 1989: | 23490
|
| 1990: | 24938
|
| 1991: | 26386
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 45
|
|
