Power: 88 hp Date of manufacture : 1990 - 1991
Production Manufacturer: CaseIH Type: Utility tractor Factory: Neuss, Germany Original price: $28,500 (1991) CaseIH 5120 Power Engine: 88 hp 65.6 kW PTO (claimed): 77 hp 57.4 kW CaseIH 5120 Engine Mechanical Chassis: 4x2 2WD   4x4 MFWD 4WD Final drives: planetary Differential lock: electrically activated Steering: power Brakes: hydraulic wet disc Cab: Flat-deck platform with two-post ROPS. Optional canopy or foldable ROPS. Cab optional with air-conditioning. Transmissions: 16-speed fully synchronized   16-speed partial power shift   24-speed creeper Photos CaseIH 5120 photos... Hydraulics Type: closed center pressure flow compensated Pressure: 2600 psi 179.3 bar Valves: 1 to 3 Total flow: 20.1 gpm 76.1 lpm Tractor hitch Rear Type: II Control: lower link Rear lift (at 24"/610mm): 7700 lbs 3492 kg Front Hitch: II*Optional Front lift (at 24"/610mm): 5200 lbs 2358 kg Power Take-off (PTO) Rear PTO: independent Clutch: hydraulic wet disc Rear RPM: 540/1000 Dimensions & Tires 2WD Wheelbase: 94.3 inches 239 cm 4WD Wheelbase: 92.3 inches 234 cm Weight: 8820 to 10362 pounds Front tire: 10.00-16 2WD Rear tire: 18.4-34 5120 Serial Numbers Location: Inside cab on left 1990: JJF1000001 1991: JJF1006114 how to read serial numbers... Electrical Ground: negative Charging system: alternator Charging amps: 65 Battery volts: 12

CaseIH 4494	Power: 213 hp	Date of manufacture : 1984 - 1987

CaseIH 4694	Power: 261 hp	Date of manufacture : 1984 - 1987

CaseIH 4894	Power: 300 hp	Date of manufacture : 1984 - 1987

CaseIH 4994	Power: 400 hp	Date of manufacture : 1984 - 1987

CaseIH 5120	Power: 88 hp	Date of manufacture : 1990 - 1991

CaseIH 5120	Power: 94 hp	Date of manufacture : 1990 - 1997

CaseIH 5130	Power: 99 hp	Date of manufacture : 1990 - 1991

CaseIH 5130	Power: 105 hp	Date of manufacture : 1990 - 1997

CaseIH 5140	Power: 108 hp	Date of manufacture : 1990 - 1991
