| Production |
| Manufacturer: | CaseIH
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Total built: | 224
|
| Original price: | $130,000 (1987)
|
| CaseIH 4994 Power |
| Engine: | 400 hp
298.3 kW
|
| PTO (claimed): | 344 hp
256.5 kW
|
| Drawbar (tested): | 294.24 hp
219.4 kW
|
| PTO (tested): | 344 hp
256.5 kW
|
| Mechanical |
| Chassis: | 4x4 4WD
|
| Steering: | hydraulic, front, rear or four-wheel crab steering
|
| Brakes: | hydraulic dual caliper disc
|
| Cab: | Silent Guardian cab standard
|
| Transmission: | 12-speed full power shift
|
| Capacity |
| Fuel: | 300 gal
1135.5 L
|
| Hydraulic system: | 26.5 gal
100.3 L
|
| Front hubs: | 13.5 qts
12.8 L (each)
|
| Front diff.: | 17 qts
16.1 L
|
| Rear hubs: | 13.5 qts
12.8 L (each)
|
| Rear diff.: | 22.5 qts
21.3 L
|
| Hydraulics |
| Type: | closed center
|
| Capacity: | 26.5 gal
100.3 L
|
| Pressure: | 2000 psi
137.9 bar
|
| Valves: | 4
|
| Total flow: | 35 gpm
132.5 lpm
|
| Steering flow: | 20 gpm
75.7 lpm
|
| Steering press.: | 2000 psi
137.9 bar
|
| Power Take-off (PTO) |
| Rear PTO: | independent (optional)
|
| Rear RPM: | 1000
|
| Engine RPM: | 1000@2100
|
| Dimensions & Tires |
| Wheelbase: | 124.8 inches
316 cm
|
| Weight: | 26500 to 31315 pounds
|
| Front tire: | 24.5-32
|
| Rear tire: | 24.5-32
|
| Full dimensions and tires ... |
| 4994 Serial Numbers |
| Location: | Data plates located at forward-right corner in top of the tractor cab.
|
| 1984: | 8865000 (JI Case)
|
| 1985: | 8866200
|
| 1986: | 8866971
|
| 1987: | 8867559
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 105
|
| Batteries: | 2
|
| Battery volts: | 12
|
| Battery AH: | 300
|
| Battery Group: | 30H
|
|
