CaseIH 785 Tractors

CaseIH 785
Power: 77 hp
Date of manufacture :
1985 - 1990
Production
Manufacturer:CaseIH
Type:Utility tractor
Factory:Doncaster, England
CaseIH 785 Power
Engine:77 hp
57.4 kW
PTO (claimed):69 hp
51.5 kW
CaseIH 785 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post ROPS. Cab available in the 795 XL version.
Transmission:16-speed
Power Take-off (PTO)
Rear RPM:540/1000
Dimensions & Tires
2WD Wheelbase:88.2 inches
224 cm
4WD Wheelbase:85.4 inches
216 cm
Weight:6376 to 7480 pounds
Front tire:7.50x18
Rear tire:16.9x34 (2WD)
Full dimensions and tires ...
