| Production |
| Manufacturer: | CaseIH
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Fargo, North Dakota, USA
|
| Original price: | $77,000 (1990)
|
| CaseIH 9130 Power |
| Engine: | 220 hp
164.1 kW
|
| PTO (claimed): | 190 hp
141.7 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Steering: | hydrostatic power for steerable front axle and articulated chassis
|
| Cab: | Cab standard.
|
| Transmission: | 12-speed full power shift
|
| Capacity |
| Fuel: | 115 gal
435.3 L
|
| Hydraulic system: | 18 gal
68.1 L
|
| Hydraulics |
| Type: | closed center
|
| Capacity: | 18 gal
68.1 L
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 2 to 4
|
| Total flow: | 27 gpm
102.2 lpm
|
| Tractor hitch |
| Optional Rear Type: | III
|
| Rear lift: | 12,750 lbs
5783 kg
|
| Power Take-off (PTO) |
| Optional Rear PTO: | independent
|
| Rear RPM: | 1000
|
| Dimensions & Tires |
| Wheelbase: | 124 inches
314 cm
|
| Weight: | 17,600 lbs
7983 kg
|
| Front tire: | 18.4-38
|
| Rear tire: | 18.4-38
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
|
