CaseIH Farmall 35 Tractors
 |
|
Power: 35 hp
Date of manufacture : 2008 - 2011 |
| Production |
| Distributor: | CaseIH
|
| Manufacturer: | Shibaura
|
| Type: | Compact Utility tractor
|
| Factory: | Dublin, Georgia, USA
|
| Original price: | $24,342 (2011 )
|
| CaseIH Farmall 35 Power |
| Engine (gross): | 35 hp
26.1 kW
|
| PTO (claimed): | 28.9 hp
21.6 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS.
|
| Transmission: | hydrostatic
|
| Photos |
| | CaseIH Farmall 35 photos... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 7.2 gpm
27.3 lpm
|
| Total flow: | 12.3 gpm
46.6 lpm
|
| Steering flow: | 5.1 gpm
19.3 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at 24"/610mm): | 1,635 lbs
741 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live
|
| Rear RPM: | 540
|
| Mid PTO: | standard
|
| Mid RPM: | 2000
|
| Dimensions & Tires |
| Wheelbase: | 63 inches
160 cm
|
| Weight: | 2,526 lbs
1145 kg
|
| Front tire: | 7x14
|
| Rear tire: | 11.2x24
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 40
|
| Battery CCA: | 420
|
| Battery volts: | 12
|
|
