Power: 75 hp Date of manufacture : 2004 - 2008
Production Manufacturer: CaseIH Type: Utility tractor Factory: Jesi, Italy CaseIH JX1075C Power Engine (gross): 75 hp 55.9 kW PTO (claimed): 62 hp 46.2 kW Drawbar (tested): 55.3 hp 41.2 kW PTO (tested): 64.5 hp 48.1 kW CaseIH JX1075C Engine Mechanical Chassis: 4x2 2WD   4x4 MFWD 4WD Steering: power Brakes: hydraulic wet disc Cab: Two-post folding ROPS. Cab optional. Transmissions: 16-speed mechanical shuttle   16-speed power shuttle Hydraulics Type: open center Pressure: 2755 psi 190.0 bar Valves: 1 to 4 Pump flow: 16.9 gpm 64.0 lpm Steering flow: 9.4 gpm 35.6 lpm Tractor hitch Rear Type: II Control: mechanical lower-link draft sensing. Rear lift: 3960 lbs 1796 kg Power Take-off (PTO) Rear PTO: independent Clutch: mechanical dry disc Rear RPM: 540 (1.375) Dimensions & Tires 2WD Wheelbase: 83.9 inches 213 cm 4WD Wheelbase: 81.3 inches 206 cm Weight: 6085 to 6615 pounds Full dimensions and tires ... Electrical Ground: negative Charging system: alternator ROPS Charging amps: 65 Cab Charging amps: 85 Battery CCA: 730 Battery volts: 12
