| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Factory: | Doncaster, England
|
| Original price: | $51,000 (1999)
|
| CaseIH MX100C Power |
| Engine: | 100 hp
74.6 kW
|
| PTO (claimed): | 83 hp
61.9 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Cab standard.
|
| Transmissions: | 16-speed partial power shift
|
| | 32-speed creeper
|
| Capacity |
| Fuel: | 50 gal
189.3 L
|
| Hydraulic system: | 17.5 gal
66.2 L
|
| Hydraulics |
| Type: | closed center pressure-flow compensating (PFC)
|
| Capacity: | 17.5 gal
66.2 L
|
| Pressure: | 2950 psi
203.4 bar
|
| Valves: | 2 to 4
|
| Pump flow: | 25 gpm
94.6 lpm
|
| Total flow: | 28.9 gpm
109.4 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | electronic lower link
|
| Rear lift (at 24"/610mm): | 8,393 lbs
3807 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electrically-actuated wet disc
|
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 540@1875
1000@2210
|
| Dimensions & Tires |
| Wheelbase: | 95.4 inches
242 cm
|
| Weight: | 10,472 lbs
4750 kg
|
| Front tire: | 14.9R-24
|
| Rear tire: | 18.4R-34
|
| Full dimensions and tires ... |
| MX100C Serial Numbers |
| Location: | Serial plate on front-left corner cab post
|
| 1998: | JJE1050021
|
| 1999: | JJE1052034
|
| 2000: | JJE1053772
|
| 2001: | JJE1055506
|
| 2002: | JJE1056230
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 95
|
| Charging volts: | 12
|
| Batteries: | 2
|
| Battery CCA: | 700
|
| Battery volts: | 12
|
|
