| Production |
| Manufacturer: | CaseIH
|
| Factories: | Racine, Wisconsin, USA
|
| | Doncaster, England
|
| Original price: | $49,000 (1999 )
|
| CaseIH MX120 Power |
| Engine: | 120 hp
89.5 kW
|
| PTO (claimed): | 105 hp
78.3 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | electrically-actuated wet disc
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Cab standard. Two-post folding ROPS available.
|
| Transmissions: | 16-speed synchromesh
|
| | 16-speed partial power shift
|
| | 32-speed creeper
|
| Photos |
| | CaseIH MX120 photos... |
| Capacity |
| Fuel: | 72 gal
272.5 L
|
| Hydraulic system: | 17.5 gal
66.2 L
|
| Hydraulics |
| Type: | closed center pressure flow compensated (PFC)
|
| Capacity: | 17.5 gal
66.2 L
|
| Pressure: | 2950 psi
203.4 bar
|
| Valves: | 2 to 4
|
| Pump flow: | 25 gpm
94.6 lpm
|
| Total flow: | 28.9 gpm
109.4 lpm
|
| Tractor hitch |
| Rear Type: | II/IIIN
|
| Control: | electronic lower link
|
| Rear lift (at 24"/610mm): | 8,393 lbs
3807 kg
|
| | 9,717 lbs
4407 kg (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000 (1.375)
|
| Dimensions & Tires |
| 2WD Wheelbase: | 110.7 inches
281 cm
|
| 4WD Wheelbase: | 106.3 inches
270 cm
|
| Weight: | 11300 to 12460 pounds
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4R-38
|
| MX120 Serial Numbers |
| Location: | On inside of cab post near left door.
|
| 1997: | JJA0075300
|
| 1998: | JJA0083000
|
| 1999: | JJA0097438
|
| 2000: | JJA0103445
|
| 2001: | JJA0108300
|
| 2002: | JJA0115301
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| ROPS Charging amps: | 65
|
| Cab Charging amps: | 95
|
| Charging volts: | 12
|
| Batteries: | 2
|
| Battery CCA: | 900
|
| Battery volts: | 12
|
|
