| Production |
| Manufacturer: | CaseIH
|
| Original price: | $76,000 (1999 )
|
| CaseIH MX150 Power |
| PTO (claimed): | 130 hp
96.9 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard.
|
| Transmissions: | 16-speed partial power shift
|
| | 32-speed creeper
|
| Capacity |
| Fuel: | 92 gal
348.2 L
|
| Hydraulic system: | 25.5 gal
96.5 L
|
| Hydraulics |
| Type: | closed center pressure-flow compensated (PFC)
|
| Capacity: | 25.5 gal
96.5 L
|
| Pressure: | 2950 psi
203.4 bar
|
| Valves: | 2 to 4
|
| Pump flow: | 28 gpm
106.0 lpm
|
| Total flow: | 31.6 gpm
119.6 lpm
|
| Tractor hitch |
| Rear Type: | II/III/IIIN
|
| Control: | electronic lower link
|
| Rear lift (at 24"/610mm): | 14,737 lbs
6684 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electrically-actuated wet disc
|
| Rear RPM: | 540/1000 (1.375)
|
| Dimensions & Tires |
| 2WD Wheelbase: | 112.2 inches
284 cm
|
| 4WD Wheelbase: | 116.6 inches
296 cm
|
| Weight: | 14,000 lbs
6350 kg
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4R-38
|
| Full dimensions and tires ... |
| MX150 Serial Numbers |
| 1998: | JJA0083000
|
| 1999: | JJA0097438
|
| 2000: | JJA0103445
|
| 2001: | JJA0108300
|
| 2002: | JJA0115301
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 95
|
| Charging volts: | 12
|
| Batteries: | 2
|
| Battery CCA: | 950
|
| Battery volts: | 12
|
|
