| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Factory: | Basildon, England
|
| Original price: | $39,100 (2005 )
|
| CaseIH MXU100 Power |
| Engine (gross): | 100 hp
74.6 kW
|
| PTO (claimed): | 80 hp
59.7 kW
|
| Drawbar (tested): | 74.7 hp
55.7 kW
|
| PTO (tested): | 87.7 hp
65.4 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | planetary inboard
|
| Differential lock: | electro-hydraulic rear standard
|
| | front optional
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Cab optional
|
| Transmissions: | 24-speed partial powershift
|
| | 16-speed partial powershift
|
| | 12-speed
|
| Photos |
| | CaseIH MXU100 photos... |
| Hydraulics |
| Type: | pressure-flow compensated (PFC) optional
|
| Pressure: | 2974 psi
205.1 bar
|
| | 3118 psi
215.0 bar (PFC)
|
| Rear valves: | 2 to 4
|
| Pump flow: | 19.8 gpm
74.9 lpm
|
| | 26.5 gpm
100.3 lpm (PFC)
|
| Total flow: | 30.3 gpm
114.7 lpm
|
| | 37 gpm
140.0 lpm (PFC)
|
| Steering flow: | 10.5 gpm
39.7 lpm
|
| Tractor hitch |
| Rear Type: | II (ROPS)
|
| | II/IIIN (cab)
|
| Control: | mechanical lower link (ROPS)
|
| | electronic draft control (cab)
|
| Rear lift: | 9,285 lbs
4211 kg
|
| | 12,185 lbs
5527 kg (with cab)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | electro-hydraulic wet plates
|
| Rear RPM: | 540/1000
|
| Engine RPM: | 540@1969
1000@2120
|
| Dimensions & Tires |
| 2WD Wheelbase: | 93.3 inches
236 cm
|
| 4WD Wheelbase: | 94.9 inches
241 cm
|
| Weight: | 9060 to 11200 pounds
|
| Front tire: | 7.50x16
|
| 2WD Rear tire: | 16.9R38
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| ROPS Charging amps: | 70
|
| Cab Charging amps: | 120
|
| Battery CCA: | 1300
|
| Battery volts: | 12
|
|
