Power: 142 hp Date of manufacture : 2002 - 2007
Production Manufacturer: CaseIH Type: Row-Crop tractor Factory: Basildon, England CaseIH MXM140 Power Engine: 142 hp 105.9 kW PTO (claimed): 115 hp 85.8 kW Drawbar (tested): 101.2 hp 75.5 kW PTO (tested): 121.1 hp 90.3 kW CaseIH MXM140 Engine Mechanical Chassis: 4x2 2WD   4x4 MFWD 4WD Steering: hydrostatic power Brakes: differential hydraulic wet disc Transmission: 18-speed partial power shift Photos CaseIH MXM140 photos... Capacity Fuel: 75 gal 283.9 L Hydraulic system: 23.75 gal 89.9 L Hydraulics Type: closed-center load sensing Capacity: 23.75 gal 89.9 L Pressure: 2750 psi 189.6 bar Valves: 2 to 5 Pump flow: 25 gpm 94.6 lpm Total flow: 28 gpm 106.0 lpm (implement pump)   44 gpm 166.5 lpm (total) Tractor hitch Rear Type: III/II Control: electronic lower-link sensing Rear lift (at 24"/610mm): 11,690 lbs 5302 kg Power Take-off (PTO) Rear PTO: independent Clutch: electro-hydraulic Rear RPM: 540/1000 (1.375) Dimensions & Tires Wheelbase: 108.1 inches 274 cm (2WD)   107.2 inches 272 cm (4WD) Weight: 10472 to 12935 pounds Full dimensions and tires ... Electrical Ground: negative Charging system: alternator Charging amps: 120 Battery CCA: 1300 Battery volts: 12 Battery AH: 176

CaseIH MX285	Power: 287 hp	Date of manufacture : 2003 - 2006

CaseIH MX305	Power: 304 hp	Date of manufacture : 2006 - 2007

CaseIH MXM120	Power: 122 hp	Date of manufacture : 2002 - 2007

CaseIH MXM130	Power: 129 hp	Date of manufacture : 2002 - 2007

CaseIH MXM140	Power: 142 hp	Date of manufacture : 2002 - 2007

CaseIH MXM155	Power: 153 hp	Date of manufacture : 2002 - 2007

CaseIH MXM175	Power: 174 hp	Date of manufacture : 2002 - 2007

CaseIH MXM190	Power: 190 hp	Date of manufacture : 2002 - 2007

CaseIH MXU100	Power: 100 hp	Date of manufacture : 2004 - 2006
