| Production |
| Manufacturer: | CaseIH
|
| Type: | Row-Crop tractor
|
| Factory: | Basildon, England
|
| Original price: | $207,893 (2015 CVT )
|
| Original price: | $195,731 (2015 power shift )
|
| CaseIH Puma 220 Power |
| Engine: | 220 hp
164.1 kW
|
| PTO (claimed): | 190 hp
141.7 kW
|
| Drawbar (tested): | 156.5 hp
116.7 kW
|
| PTO (tested): | 209.6 hp
156.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Trailer brakes: | hydraulic*Optional
|
| | pneumatic*Optional
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 18-speed full power shift
|
| | continuously variable transmission (CVT)
|
| Hydraulics |
| Type: | closed center pressure flow compensating
|
| Valves: | 3 to 5
|
| Pump flow: | 30 gpm
113.6 lpm
|
| | 39.6 gpm
149.9 lpm *Optional
|
| Total flow: | 47 gpm
177.9 lpm
|
| | 56.6 gpm
214.2 lpm *Optional
|
| Steering flow: | 17 gpm
64.3 lpm
|
| Tractor hitch |
| Rear Type: | II/IIIN
|
| Rear lift: | 12787 lbs
5800 kg
|
| | 15000 lbs
6804 kg *Optional
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000 (1.375)
|
| | 1000/1000E (1.75)
|
| Dimensions & Tires |
| Wheelbase: | 113.6 inches
288 cm
|
| Weight: | 15900 to 16800 pounds
|
| Front tire: | 420/85R30
|
| Rear tire: | 520/85R42
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 150
|
| Battery volts: | 12
|
|
