Navigation: Home > CaseIH > Puma 240

CaseIH Puma 240 Tractors

CaseIH Puma 240
Power: 240 hp
Date of manufacture :
0000 - 0000
Production
Manufacturer:CaseIH
Type:Row-Crop tractor
Factory:Basildon, England
Original price:$216,959 (2015 )
CaseIH Puma 240 Power
Engine:240 hp
179.0 kW
PTO (claimed):205 hp
152.9 kW
Drawbar (tested):173.2 hp
129.2 kW
PTO (tested):228.6 hp
170.5 kW
CaseIH Puma 240 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with air-conditioning.
Transmissions:18-speed full power shift
 continuously variable transmission (CVT)
Hydraulics
Type:closed center pressure flow compensating
Valves:3 to 5
Pump flow:30 gpm
113.6 lpm
 39.6 gpm
149.9 lpm *Optional
Total flow:47 gpm
177.9 lpm
 56.6 gpm
214.2 lpm *Optional
Steering flow:17 gpm
64.3 lpm
Tractor hitch
Rear Type:II/IIIN
Rear lift:12787 lbs
5800 kg
 15000 lbs
6804 kg *Optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000/1000E (1.75)
Dimensions & Tires
Wheelbase:113.6 inches
288 cm
Weight:16800 lbs
7620 kg
Front tire:420/85R30
Rear tire:520/85R42
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Battery volts:12
