| Production |
| Manufacturer: | Cockshutt
|
| Type: | Row-Crop tractor
|
| Factory: | Charles City, Iowa, USA
|
| Original price: | $12,000 (1969)
|
| Cockshutt 2050 Power |
| PTO (claimed): | 118 hp
88.0 kW
|
| Drawbar (tested): | 96.36 hp
71.9 kW
|
| PTO (tested): | 118.78 hp
88.6 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | planetary
|
| Steering: | power
|
| Brakes: | independent disc
|
| Cab: | Open operator station. Cab optional with air-conditioning.
|
| Transmissions: | 6-speed unsynchronized gear
|
| | 18-speed partial powershift
|
| Tractor hitch |
| Rear Type: | III
|
| Control: | position and draft control
|
| Rear lift (at 24"/610mm): | 6000 lbs
2721 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 97.7 inches
248 cm
|
| Weight: | 14,540 lbs
6595 kg
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4-38
|
| Full dimensions and tires ... |
| 2050 Serial Numbers |
| 1968: | 204444
|
| 1969: | 212560
|
| Final: | 213932
|
how to read serial numbers...
| |
