| Production |
| Distributor: | Cub Cadet
|
| Manufacturer: | Mitsubishi
|
| Type: | Compact Utility tractor
|
| Original price: | $13,800 (2007)
|
| Cub Cadet 7532 Power |
| Engine: | 32 hp
23.9 kW
|
| PTO (claimed): | 25.5 hp
19.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | standard
|
| Steering: | hydrostatic power
|
| Brakes: | mechanical wet disc
|
| Cab: | Two-post foldable ROPS
|
| Transmission: | hydrostatic
|
| Capacity |
| Fuel: | 7.1 gal
26.9 L
|
| Hydraulic system: | 8.2 gal
31.0 L
|
| Front axle: | 4.2 qts
4.0 L
|
| Hydraulics |
| Type: | gear pump
|
| Capacity: | 8.2 gal
31.0 L
|
| Pressure: | 2204 psi
152.0 bar
|
| Pump flow: | 7.2 gpm
27.3 lpm
|
| Total flow: | 10.5 gpm
39.7 lpm
|
| Steering flow: | 3.3 gpm
12.5 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at ends): | 2,646 lbs
1200 kg
|
| Rear lift (at 24"/610mm): | 1,720 lbs
780 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 540@2376
|
| Mid PTO: | optional
|
| Mid RPM: | 2000
|
| Dimensions & Tires |
| Wheelbase: | 67.3 inches
170 cm
|
| Weight: | 2,456 lbs
1114 kg
|
| Front tire: | 7-16
|
| Rear tire: | 11.2-24
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 50
|
| Charging volts: | 12
|
| Battery CCA: | 500
|
| Battery volts: | 12
|
|
