Navigation: Home > Deutz-Fahr > 9310 TTV

Deutz-Fahr 9310 TTV Tractors

Deutz-Fahr 9310 TTV
Power: 296 hp
Date of manufacture :
0000 - 0000
Production
Manufacturer:Deutz-Fahr
Type:Row-Crop tractor
Deutz-Fahr 9310 TTV Power
Engine (gross):296 hp
220.7 kW
Engine (max):312 hp
232.7 kW
Deutz-Fahr 9310 TTV Engine
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:automatic front and rear differential locks
Steering:power
Brakes:wet disc
Cab:MaxiVision II Cab standard with air-conditioning.
Hydraulics
Type:closed center load sensing
Valves:4 to 8
Pump flow:42.3 gpm
160.1 lpm
 55.5 gpm
210.1 lpm *Optional.
Tractor hitch
Rear lift:26455 lbs
11999 kg
Front lift:11023 lbs
5000 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540E/1000/1000E
Front PTO:independent*Optional.
Clutch:electro-hydraulic
Front RPM:1000
 1000E
Dimensions & Tires
Wheelbase:123.4 inches
313 cm
Weight:26455 lbs
11999 kg
Front tire:650/65R34
Rear tire:710/75R42
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:200
Battery volts:12
Battery AH:180
