| Production |
| Manufacturer: | Farmall (a part of International Harvester)
|
| Factories: | Louisville, Kentucky, USA
|
| | Chicago, Illinois, USA
|
| Total built: | 107,636
|
| Original price: | $1,400 (1954)
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | differential mechanical contracting band
|
| Cab: | Open operator station.
|
| Transmission: | 4-speed sliding gear
|
| Photos |
| | Farmall Super A photos... |
| Capacity |
| Fuel: | 11 gal
41.6 L
|
| Aux. fuel: | 0.75 gal
2.8 L
|
| Hydraulic system: | 2.1 gal
7.9 L
|
| Rear hubs: | 3 qts
2.8 L (each)
|
| Hydraulics |
| Type: | IH Touch-Control
|
| Capacity: | 2.1 gal
7.9 L
|
| Valves: | 1
|
| Tractor hitch |
| Type: | mid-mount Touch Control rockshaft
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 540
|
| Dimensions & Tires |
| Wheelbase: | 71.1 inches
180 cm
|
| Weight: | 2,400 lbs
1088 kg
|
| Front tire: | 5.00-15
|
| Rear tire: | 9-24
|
| Full dimensions and tires ... |
| Super A Serial Numbers |
| Location: | On the right side of the seat support
|
photo of Super A serial number
| | 1947: | 250001
|
| 1948: | 250082
|
| 1949: | 268196
|
| 1950: | 281269
|
| 1951: | 300126
|
| 1952: | 324470
|
| 1953: | 336880
|
| 1954: | 353348
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 8.5 inches
21 cm
|
| Width: | 6 inches
15 cm
|
| RPM: | 1157
|
| Speed: | 2574 ft/min
784.56 meters/min
|
| Electrical |
| Ground: | postitive
|
| Battery volts: | 6
|
|
