Ford-New Holland 8530 Tractors
 |
|
Power: 116 hp[P]
Date of manufacture : 1990 - 1993 |
| Production |
| Manufacturer: | Ford-New Holland
|
| Type: | Row-Crop tractor
|
| Factory: | Antwerp, Belgium
|
| Original price: | $46,000 (1993)
|
| Ford-New Holland 8530 Power |
| Drawbar (claimed): | 92 hp
68.6 kW
|
| PTO (claimed): | 105 hp
78.3 kW
|
| Drawbar (tested): | 92.62 hp
69.1 kW
|
| PTO (tested): | 105.74 hp
78.9 kW
|
| Ford-New Holland 8530 Engine |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | Power disc
|
| Cab: | optional cab with heat and A/C
|
| Transmissions: | 16-speed
|
| | 8-speed
|
| Capacity |
| Fuel: | 33 gal
124.9 L
|
| | 24.5 gal
92.7 L (auxiliary tank)
|
| Steering: | 2 qts
1.9 L
|
| Hydraulics |
| Type: | open center gear pump, dual pumps optional
|
| Pressure: | 2500 psi
172.4 bar
|
| Pump flow: | 20.9 gpm
79.1 lpm
|
| | 29.6 gpm
112.0 lpm (dual pumps)
|
| SCV flow: | 17.6 gpm
66.6 lpm
|
| | 19.0 gpm
71.9 lpm (dual pumps)
|
| Steering cap.: | 2 qts
1.9 L
|
| Steering press.: | 2025 psi
139.6 bar
|
| Tractor hitch |
| Rear Type: | 2
|
| Control: | position and draft control
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 105 inches
266 cm
|
| Weight: | 11395 to 13920 pounds
|
| Front tire: | 11.00-16
|
| Rear tire: | 18.4/15-38
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 90
|
| Battery volts: | 12
|
|
