International Harvester 154 Lo-Boy Tractors
 |
|
Power: 15 hp[P]
Date of manufacture : 1968 - 1974 |
| Production |
| Manufacturer: | International Harvester
|
| Type: | Compact Utility tractor
|
| Factory: | Louisville, Kentucky, USA
|
| Original price: | $2,400 (1974)
|
| International Harvester 154 Lo-Boy Power |
| PTO (claimed): | 14 hp
10.4 kW
|
| International Harvester 154 Lo-Boy Engine |
| Mechanical |
| Chassis: | 4x2 2WD
|
| Steering: | manual
|
| Brakes: | mechanical drum
|
| Cab: | Open operator station.
|
| Transmissions: | 3-speed unsynchronized gear
|
| | 6-speed creeper
|
| Photos |
| | International Harvester 154 Lo-Boy photos... |
| Capacity |
| Fuel: | 8 gal
30.3 L
|
| Hydraulic system: | 1.75 gal
6.6 L
|
| Hydraulics |
| Type: | gear pump
|
| Capacity: | 1.75 gal
6.6 L
|
| Pressure: | 2000 psi
137.9 bar
|
| Pump flow: | 2 gpm
7.6 lpm
|
| Tractor hitch |
| Rear Type: | I (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | mechanical dry disc
|
| Rear RPM: | 1600 (counter-clockwise)
|
| Dimensions & Tires |
| Wheelbase: | 64 inches
162 cm
|
| Weight: | 1480 lbs
671 kg
|
| Front tire: | 4.00-12
|
| Rear tire: | 8.3-24
|
| 154 Lo-Boy Serial Numbers |
| Location: | Frame, front left side
|
photo of 154 Lo-Boy serial number
| | 1968: | 7505
|
| 1969: | 8273
|
| 1970: | 15502
|
| 1971: | 20332
|
| 1972: | 23343
|
| 1973: | 27538
|
| 1974: | 31766
|
| Final: | 36676
|
how to read serial numbers...
|
| Links |
| McCormick-Deering Farmall Cub: |
| Electrical |
| Ground: | negative
|
| Charging amps: | 12, 15 (generator)
|
| Battery volts: | 12
|
|
