International Harvester 433 Tractors

International Harvester 433
Power: 35 hp
Date of manufacture :
1975 - 1980
Production
Manufacturer:International Harvester
Type:Utility tractor
Factory:Neuss, Germany
Variants
433:utility
433V:vineyard
International Harvester 433 Power
Engine:35 hp
26.1 kW
International Harvester 433 Engine
Mechanical
Chassis:4x2 2WD
Differential lock:mechanical rear
Steering:manual
Brakes:disc
Cab:Open operator station. Cab optional.
Transmissions:8-speed
 16-speed
Capacity
Fuel:15.85 gal
60.0 L
Hydraulic system:3.2 gal
12.1 L
Hydraulics
Capacity:3.2 gal
12.1 L
Pump flow:7.9 gpm
29.9 lpm
Tractor hitch
Rear Type:II
Rear lift:3969 lbs
1800 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Dimensions & Tires
Wheelbase:81.5 inches
207 cm
Weight:4608 lbs
2090 kg
Front tire:6.00-16
Rear tire:12.4/11x28
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:28
Charging volts:14
Battery volts:12
Battery AH:88
