International Harvester 966 Tractors
 |
|
Power: 91 hp
Date of manufacture : 1971 - 1976 |
| Production |
| Manufacturer: | International Harvester
|
| Type: | Row-Crop tractor
|
| Total built: | 21,017
|
| Original price: | $18,000 (1976 )
|
| Variants |
| Hi-Clear: | high-crop model
|
| International Harvester 966 Power |
| Engine: | 91 hp
67.9 kW
|
| Drawbar (claimed): | 84 hp
62.6 kW
|
| PTO (claimed): | 95 hp
70.8 kW
|
| Drawbar (tested): | 85.21 hp
63.5 kW
|
| PTO (tested): | 100.80 hp
75.2 kW
|
| International Harvester 966 Engine |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | Independent hydraulic dry disc
|
| Cab: | Cab optional with heat and air-conditioning.
|
| Transmissions: | 8-speed sliding gear
|
| | 16-speed two-speed power shift
|
| | hydrostatic
|
| Capacity |
| Fuel: | 37 gal
140.0 L
|
| Hydraulic system: | 22.5 gal
85.2 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 22.5 gal
85.2 L
|
| Pressure: | 2000 psi
137.9 bar
|
| Valves: | 1 to 4
|
| Pump flow: | 12 gpm
45.4 lpm
|
| Total flow: | 24 gpm
90.8 lpm
|
| Steering flow: | 9 gpm
34.1 lpm
|
| Steering press.: | 1550 psi
106.9 bar
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at 24"/610mm): | 4400 lbs
1995 kg
|
| Type: | IH Fast Hitch
|
| Rear lift: | 5000 lbs
2268 kg (at 24 inches)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 105 inches
266 cm
|
| Weight: | 11116 to 11700 pounds
|
| Front tire: | 9.5L-15
|
| Rear tire: | 18.4-34
|
| Full dimensions and tires ... |
| 966 Serial Numbers |
| Location: | Clutch housing, left side
|
| 1971: | 7101
|
| 1972: | 11815
|
| 1973: | 17794
|
| 1974: | 22526
|
| 1975: | 28119
|
| 1976: | 31772
|
how to read serial numbers...
|
| Electrical |
| Charging amps: | 32
|
| Batteries: | 2
|
| Battery volts: | 6
|
| Battery AH: | 172
|
|
