Kioti EX35 Tractors

Kioti EX35
Power: 38 hp
Date of manufacture :
2008 - 2013
Production
Manufacturer:Kioti (a part of Daedong)
Type:Compact Utility tractor
Factory:South Korea
Kioti EX35 Power
Engine (gross):38 hp
28.3 kW
Shuttle PTO (claimed):27.5 hp
20.5 kW
Hydro PTO (claimed):26.1 hp
19.5 kW
Kioti EX35 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Cab standard with air-conditioning.
Transmissions:24-speed synchro shuttle
 hydrostatic
Hydraulics
Type:open center
Pump flow:15.3 gpm
57.9 lpm
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift (at ends):5694.5 lbs
2583 kg
Rear lift (at 24"/610mm):5253.6 lbs
2383 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Mid RPM:2000
Dimensions & Tires
Wheelbase:69.5 inches
176 cm
Weight:4131 to 4138 pounds
Front tire:7-16
Rear tire:12.4-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Battery volts:12
