Power: 35 hp Date of manufacture : 0000 - 0000
Production Manufacturer: LS Type: Compact Utility tractor LS XR3135 Power Engine (gross): 35 hp 26.1 kW Hydro PTO (claimed): 28 hp 20.9 kW Shuttle PTO (claimed): 30.1 hp 22.4 kW LS XR3135 Engine Mechanical Chassis: 4x4 MFWD 4WD Steering: power Brakes: wet disc Cab: Two-post folding ROPS. Cab optional with available air-conditioning. Transmissions: 12-speed synchronized shuttle   hydrostatic Hydraulics Valves: 2 Pump flow: 8.2 gpm 31.0 lpm Shuttle Total flow: 12.3 gpm 46.6 lpm Hydro Total flow: 13.7 gpm 51.9 lpm Shuttle Steering flow: 4.1 gpm 15.5 lpm Hydro Steering flow: 5.5 gpm 20.8 lpm Tractor hitch Rear Type: I Control: position and draft control Rear lift (at ends): 1808 lbs 820 kg Power Take-off (PTO) Rear PTO: independent Rear RPM: 540 (1.375) Mid RPM: 2000 Dimensions & Tires Wheelbase: 66 inches 167 cm Weight: 3219 to 3655 pounds Front tire: 7-14 Rear tire: 11.2-24 Electrical Ground: negative Charging system: alternator Charging amps: 70 Charging volts: 12 Battery volts: 12

LS XR3032	Power: 32 hp	Date of manufacture : 2013 - 2018

LS XR3032H	Power: 32 hp	Date of manufacture : 2013 - 2018

LS XR3037	Power: 36 hp	Date of manufacture : 2013 - 2018

LS XR3037H	Power: 36 hp	Date of manufacture : 2013 - 2018

LS XR3135	Power: 35 hp	Date of manufacture : 0000 - 0000

LS XR3140	Power: 40 hp	Date of manufacture : 0000 - 0000

LS XR4040	Power: 40 hp	Date of manufacture : 2013 - 2018

LS XR4040H	Power: 40 hp	Date of manufacture : 2013 - 2018

LS XR4046	Power: 46 hp	Date of manufacture : 2013 - 2018
