LS XR4040 Tractors

LS XR4040
Power: 40 hp
Date of manufacture :
2013 - 2018
Production
Manufacturer:LS
Type:Compact Utility tractor
LS XR4040 Power
Engine (gross):40 hp
29.8 kW
PTO (claimed):32.4 hp
24.2 kW
LS XR4040 Engine
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS. Cab optional with air-conditioning.
Transmission:16-speed synchro shuttle
Hydraulics
Pump flow:8.2 gpm
31.0 lpm
Total flow:12.4 gpm
46.9 lpm
Steering flow:4.2 gpm
15.9 lpm
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift:2756 lbs
1250 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:independent (optional)
Mid RPM:2000
Dimensions & Tires
Wheelbase:69.4 inches
176 cm
Weight:3870 to 4330 pounds
Front tire:9.5-16
Rear tire:13.6-24
Electrical
Ground:negative
Charging system:alternator
Charging amps:85
Battery volts:12
