Steiger Turbo Tiger Tractors
 |
|
Power: 320 hp
Date of manufacture : 1973 - 1974 |
| Production |
| Manufacturer: | Steiger
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Fargo, North Dakota, USA
|
| Original price: | $39,000 (1974 )
|
| Steiger Turbo Tiger Power |
| Engine: | 320 hp
238.6 kW
|
| Drawbar (claimed): | 235 hp
175.2 kW
|
| PTO (claimed): | 256 hp
190.9 kW
|
| Steiger Turbo Tiger Engine |
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | outboard planetary
|
| Steering: | hydraulic articulated power
|
| Cab: | Climatized Cab standard with available air-conditioning.
|
| Transmission: | 10-speed gear
|
| Photos |
| | Steiger Turbo Tiger photos... |
| Capacity |
| Fuel: | 207 gal
783.5 L
|
| Hydraulic system: | 38 gal
143.8 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 38 gal
143.8 L
|
| Pressure: | 2000 psi
137.9 bar
|
| Pump flow: | 25 gpm
94.6 lpm
|
| Dimensions & Tires |
| Wheelbase: | 121.3 inches
308 cm
|
| Weight: | 21000 to 26000 pounds
|
| Front tire: | 30.5-32
|
| Rear tire: | 30.5-32
|
| Full dimensions and tires ... |
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 62
|
| Charging volts: | 12
|
| Battery volts: | 12
|
|
