| Production |
| Manufacturer: | CaseIH
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $40,000 (1989 )
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Differential lock: | electric rear
|
| Steering: | power
|
| Brakes: | differential hydraulic wet discs
|
| Cab: | Two-post folding ROPS. Cab optional with air-conditioning.
|
| Transmission: | 12-speed three-speed power shift
|
| Photos |
| | CaseIH 2096 photos... |
| Capacity |
| Fuel: | 65 gal
246.0 L
|
| Hydraulic system: | 25 gal
94.6 L
|
| Hydraulics |
| Type: | closed center
|
| Capacity: | 25 gal
94.6 L
|
| Pressure: | 2250 psi
155.1 bar
|
| Valves: | 2
|
| Pump flow: | 23 gpm
87.1 lpm
|
| Steering flow: | 8 gpm
30.3 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at 24"/610mm): | 8,250 lbs
3742 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000 (1.375)
|
| Dimensions & Tires |
| Wheelbase: | 108 inches
274 cm
|
| Weight: | 11875 to 14180 pounds
|
| Front tire: | 11.00-16
|
| 2WD Rear tire: | 18.4-38
|
| Full dimensions and tires ... |
| 2096 Serial Numbers |
| Location: | Inside cab the rear window or door
|
| 1984: | 9931800
|
| 1985: | 9938100
|
| 1986: | 9941573
|
| 1987: | 17897512
|
| 1988: | 17897658
|
| 1989: | 17898172
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 105
|
| Battery volts: | 12
|
|
