| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Original price: | $26,000 (1988)
|
| CaseIH 1594 Power |
| Engine: | 97 hp
72.3 kW
|
| Drawbar (claimed): | 74 hp
55.2 kW
|
| PTO (claimed): | 86 hp
64.1 kW
|
| Drawbar (tested): | 72.17 hp
53.8 kW
|
| PTO (tested): | 85.90 hp
64.1 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | ROPS or cab.
|
| Transmissions: | 12-speed synchromesh
|
| | 12-speed partial power shift
|
| Photos |
| | CaseIH 1594 photos... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2600 psi
179.3 bar
|
| Valves: | 2
|
| Total flow: | 10.5 gpm
39.7 lpm
|
| | 20.1 gpm
76.1 lpm (tandem)
|
| Steering flow: | 7.7 gpm
29.1 lpm
|
| Steering press.: | 1850 psi
127.6 bar
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at ends): | 7,440 lbs
3374 kg
|
| Rear lift (at 24"/610mm): | 6,290 lbs
2853 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 100 inches
254 cm
|
| Weight: | 9,290 lbs
4213 kg
|
| Front tire: | 10.00-16
|
| Rear tire: | 16.9-38
|
| Full dimensions and tires ... |
| 1594 Serial Numbers |
| Location: | On right side of main frame
|
| 1985: | 11526001
|
| 1986: | 11526518
|
| 1987: | 11527297
|
| 1988: | 11528442
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 45
|
| | 65 (heavy duty)
|
| Battery CCA: | 420
|
| | 550 (heavy duty)
|
| Battery volts: | 12
|
| Battery AH: | 96
|
| | 128 (heavy duty)
|
|
