| Production |
| Manufacturer: | CaseIH
|
| Type: | Utility tractor
|
| Original price: | $24,100 (1988 )
|
| CaseIH 1494 Power |
| Engine: | 85 hp
63.4 kW
|
| PTO (claimed): | 75 hp
55.9 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | disc
|
| Cab: | Cab optional with air-conditioning.
|
| Transmissions: | 12-speed synchromesh
|
| | 12-speed partial power shift
|
| Photos |
| | CaseIH 1494 photos... |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2475 psi
170.7 bar
|
| Valves: | 1 to 3
|
| Total flow: | 8.5 gpm
32.2 lpm
|
| | 15.3 gpm
57.9 lpm (tandem)
|
| Steering flow: | 7.7 gpm
29.1 lpm
|
| Steering press.: | 1850 psi
127.6 bar
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at ends): | 5,366 lbs
2434 kg
|
| Rear lift (at 24"/610mm): | 3,210 lbs
1456 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 88.5 inches
224 cm
|
| Weight: | 7380 to 8180 pounds
|
| Front tire: | 7.50-16
|
| Rear tire: | 18.4-34
|
| Full dimensions and tires ... |
| 1494 Serial Numbers |
| Location: | Right side of main frame
|
| 1985: | 11517001
|
| 1986: | 11519378
|
| 1987: | 11520410
|
| 1988: | 11521062
|
how to read serial numbers...
|
| Electrical |
| Charging system: | alternator
|
| Charging amps: | 45
|
| | 65 (heavy duty)
|
| Battery CCA: | 420
|
| | 550 (heavy duty)
|
| Battery volts: | 12
|
| Battery AH: | 96
|
| | 128 (heavy duty)
|
|
