CaseIH 585 Tractors

CaseIH 585
Power: 60 hp
Date of manufacture :
1985 - 1990
Production
Manufacturer:CaseIH
Type:Utility tractor
Factory:Doncaster, England
Original price:$20,000 (1990 )
Variants
585:utility
585-O:orchard
CaseIH 585 Power
Engine:60 hp
44.7 kW
PTO (claimed):52 hp
38.8 kW
CaseIH 585 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Cab:Two-post ROPS
Transmissions:8-speed synchromesh
 16-speed
Photos
CaseIH 585 photos...
Capacity
Fuel:20 gal
75.7 L
Hydraulic system:9 gal
34.1 L
Hydraulics
Type:open center
Capacity:9 gal
34.1 L
Valves:1 or 2
Pump flow:15.1 gpm
57.2 lpm
Tractor hitch
Rear Type:II/I
Rear lift (at 24"/610mm):3210 lbs
1456 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:78 inches
198 cm
Weight:5640 to 6765 pounds
Front tire:7.50-16
Rear tire:16.9-30
Full dimensions and tires ...
585 Serial Numbers
1985:15000
1986:18000
1987:19201
1988:22268
1989:24954
1990:27087

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:45
Battery volts:12
