| Production |
| Manufacturer: | CaseIH
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Original price: | $103,000
|
| CaseIH MX220 Power |
| PTO (claimed): | 185 hp
138.0 kW
|
| Drawbar (tested): | 161.21 hp
120.2 kW
|
| PTO (tested): | 209.25 hp
156.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic wet disc
|
| Cab: | Cab standard
|
| Transmissions: | 18-speed full powershift
|
| | 24-speed
|
| Capacity |
| Fuel: | 130 gal
492.1 L
|
| Hydraulic system: | 45.5 gal
172.2 L
|
| Hydraulics |
| Type: | PFC
|
| Capacity: | 45.5 gal
172.2 L
|
| Valves: | 3
|
| Pump flow: | 30 gpm
113.6 lpm
|
| Tractor hitch |
| Rear Type: | III
|
| Rear lift: | 11200 lbs
5080 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| | 1000 (1.75)
|
| Engine RPM: | 540@1982
1000@1974
|
| Dimensions & Tires |
| Wheelbase: | 118.3 inches
300 cm (4WD)
|
| Weight: | 20,010 lbs
9076 kg
|
| Front tire: | 11.00-24
|
| Rear tire: | 18.4R46
|
| Full dimensions and tires ... |
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery volts: | 12
|
|
