Power: 248 hp Date of manufacture : 2006 - 2007
Production Manufacturer: CaseIH Type: Row-Crop tractor Factory: Racine, Wisconsin, USA CaseIH MX245 Power Engine: 248 hp 184.9 kW PTO (claimed): 200 hp 149.1 kW Drawbar (tested): 172.67 hp 128.8 kW PTO (tested): 203.97 hp 152.1 kW CaseIH MX245 Engine Mechanical Chassis: 4x4 MFWD 4WD Steering: power Brakes: independent hydraulic wet disc Cab: Cab standard. Transmissions: 18-speed full power shift   19-speed full power shift - overdrive   23-speed Creeper Photos CaseIH MX245 photos... Capacity Fuel: 180 gal 681.3 L Hydraulic system: 45.5 gal 172.2 L Hydraulics Type: pressure flow compensating Capacity: 45.5 gal 172.2 L Valves: 3 to 5 Total flow: 38.6 gpm 146.1 lpm   58 gpm 219.5 lpm *Optional Tractor hitch Rear Type: III Rear lift: 13960 lbs 6332 kg   15970 lbs 7243 kg *Optional Power Take-off (PTO) Rear PTO: independent Rear RPM: 540/1000 Dimensions & Tires Wheelbase: 118.3 inches 300 cm Weight: 21185 lbs 9609 kg Full dimensions and tires ... Electrical Ground: negative Charging amps: 150   175*Optional Battery CCA: 2000 Battery volts: 12

CaseIH MX215	Power: 221 hp	Date of manufacture : 2006 - 2007

CaseIH MX220	Power: 205 hp[P]	Date of manufacture : 1999 - 2002

CaseIH MX230	Power: 234 hp	Date of manufacture : 2003 - 2006

CaseIH MX240	Power: 227 hp[P]	Date of manufacture : 1999 - 2002

CaseIH MX245	Power: 248 hp	Date of manufacture : 2006 - 2007

CaseIH MX255	Power: 262 hp	Date of manufacture : 2003 - 2006

CaseIH MX270	Power: 261 hp[P]	Date of manufacture : 1999 - 2002

CaseIH MX275	Power: 275 hp	Date of manufacture : 2006 - 2007

CaseIH MX285	Power: 287 hp	Date of manufacture : 2003 - 2006
