Power: 122 hp Date of manufacture : 2002 - 2007
Production Manufacturer: CaseIH Type: Row-Crop tractor Factory: Basildon, England CaseIH MXM120 Power Engine: 122 hp 91.0 kW PTO (claimed): 95 hp 70.8 kW Drawbar (tested): 83.0 hp 61.9 kW PTO (tested): 104.9 hp 78.2 kW CaseIH MXM120 Engine Mechanical Chassis: 4x2 2WD   4x4 MFWD 4WD Steering: power Brakes: differential hydraulic wet disc Transmissions: 18-speed partial powershift   18-speed full power shift Photos CaseIH MXM120 photos... Capacity Fuel: 75 gal 283.9 L Hydraulic system: 23.75 gal 89.9 L Hydraulics Type: closed-center load sensing Capacity: 23.75 gal 89.9 L Pressure: 2750 psi 189.6 bar Valves: 2 to 5 Pump flow: 25 gpm 94.6 lpm Total flow: 28 gpm 106.0 lpm (implement pump)   44 gpm 166.5 lpm (total) Tractor hitch Rear Type: II Control: electronic lower-link sensing Rear lift (at 24"/610mm): 8,725 lbs 3957 kg Power Take-off (PTO) Rear PTO: independent Clutch: electro-hydraulic Rear RPM: 540/1000 (1.375) Engine RPM: 540@1969 1000@2120 Dimensions & Tires 2WD Wheelbase: 108.1 inches 274 cm 4WD Wheelbase: 107.2 inches 272 cm Weight: 11283 to 11859 pounds Full dimensions and tires ... MXM120 Serial Numbers 2003: ACM191688 2004: ACM216992 2005: ACM240012 2006: ACM258550 2007: ACM283224 how to read serial numbers... Electrical Ground: negative Charging system: alternator Charging amps: 120 Battery CCA: 1300 Battery volts: 12 Battery AH: 176

CaseIH MX270	Power: 261 hp[P]	Date of manufacture : 1999 - 2002

CaseIH MX275	Power: 275 hp	Date of manufacture : 2006 - 2007

CaseIH MX285	Power: 287 hp	Date of manufacture : 2003 - 2006

CaseIH MX305	Power: 304 hp	Date of manufacture : 2006 - 2007

CaseIH MXM120	Power: 122 hp	Date of manufacture : 2002 - 2007

CaseIH MXM130	Power: 129 hp	Date of manufacture : 2002 - 2007

CaseIH MXM140	Power: 142 hp	Date of manufacture : 2002 - 2007

CaseIH MXM155	Power: 153 hp	Date of manufacture : 2002 - 2007

CaseIH MXM175	Power: 174 hp	Date of manufacture : 2002 - 2007
