Challenger MT295B Tractors

Challenger MT295B
Power: 52 hp
Date of manufacture :
2005 - 2008
Production
Distributor:Challenger (a part of AGCO)
Manufacturer:Iseki
Type:Compact Utility tractor
Factory:Matsuyama, Japan
Original price:$25,000 (2005 )
Variants
Massey Ferguson 1552
Challenger MT295B Power
Engine (gross):52.1 hp
38.9 kW
Engine (net):50 hp
37.3 kW
PTO (claimed):41 hp
30.6 kW
Challenger MT295B Engine
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:spur gear
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Two-post foldable ROPS. Cab optional with air-conditioning.
Transmissions:8-speed
 12-speed partially synchronized
 12-speed partial power shift
Capacity
Fuel:13.2 gal
50.0 L
Hydraulic system:10 gal
37.9 L
Hydraulics
Type:open center
Capacity:10 gal
37.9 L
Pressure:2276 psi
156.9 bar
Rear valves:2*Optional
Mid valves:2*Optional
Pump flow:11.4 gpm
43.1 lpm
Total flow:16.2 gpm
61.3 lpm (sync shuttle)
 17.3 gpm
65.5 lpm (power shuttle/AutoPower)
Steering flow:4.8 gpm
18.2 lpm (sync shuttle)
 5.9 gpm
22.3 lpm (power shuttle/AutoPower)
Steering press.:2276 psi
156.9 bar
Tractor hitch
Rear Type:I
Control:position and response control
 optional top-link draft control
Rear lift (at ends):3483 lbs
1579 kg
Rear lift (at 24"/610mm):3086 lbs
1399 kg
Rear Arms:telescopic link ends
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540
Dimensions & Tires
Wheelbase:76 inches
193 cm
Weight:3726 lbs
1690 kg
Front tire:9.5-16
Rear tire:16.9-24
Electrical
Ground:negative
Charging system:alternator
Charging amps:40
Battery CCA:710
Battery volts:12
