Navigation: Home > Challenger > MT535

Challenger MT535 Tractors

Challenger MT535
Power: 111 hp[P]
Date of manufacture :
2002 - 2003
Production
Manufacturer:Challenger (a part of AGCO)
Type:Row-Crop tractor
Factory:Beauvais, France
Variants
Massey Ferguson 6270
Challenger MT535 Power
PTO (claimed):100 hp
74.6 kW
Drawbar (tested):98.8 hp
73.7 kW
PTO (tested):103.9 hp
77.5 kW
Challenger MT535 Engine
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic wet disc
Cab:Cab optional with air-conditioning.
Transmission:32-speed partial power shift
Hydraulics
Type:closed center pressure flow compensated (PFC)
Pressure:2900 psi
200.0 bar
Valves:2 to 4
Total flow:28 gpm
106.0 lpm
Tractor hitch
Rear Type:II
Rear lift (at 24"/610mm):7000 lbs
3175 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:108.3 inches
275 cm
Weight:9600 to 10763 pounds
Front tire:11.00-16
Rear tire:18.4R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
