International Harvester 500 Tractors
 |
|
Power: 43 hp
Date of manufacture : 1965 - 1969 |
| Production |
| Manufacturer: | International Harvester
|
| Type: | Agricultural Crawler tractor
|
| Factory: | Hamilton, Ontario, Canada
|
| Variants |
| 500: | ag crawler
|
| 500: | industrial crawler
|
| International Harvester 500 Power |
| Engine (gross): | 47 hp
35.0 kW
|
| Engine (net): | 38 hp
28.3 kW
|
| PTO (claimed): | 36 hp
26.8 kW
|
| Drawbar (tested): | 31.24 hp
23.3 kW
|
| PTO (tested): | 37.22 hp
27.8 kW
|
| International Harvester 500 Engines |
| Mechanical |
| Chassis: | crawler
|
| Steering: | mechanical clutches
|
| Brakes: | mechanical contracting band
|
| Cab: | Open operator station.
|
| Transmissions: | 8-speed partial power shift
|
| | 5-speed unsynchronized gear
|
| Hydraulics |
| Valves: | 1 to 3
|
| Pump flow: | 7 gpm
26.5 lpm
|
| | 8 gpm
30.3 lpm (optional)
|
| | 9 gpm
34.1 lpm (optional)
|
| | 12 gpm
45.4 lpm (front optional)
|
| | 17 gpm
64.3 lpm (front optional)
|
| Tractor hitch |
| Rear Type: | I
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 1000
|
| | 540
|
| Engine RPM: | 980@2000
|
| Dimensions & Tracks |
| Wheelbase: | 67 inches
170 cm
|
| Weight: | 7050 to 7260 pounds
|
| 12-inch shoes |
| Full dimensions and tracks ... |
| 500 Serial Numbers |
| 1965: | 501
|
| 1966: | 891
|
| 1967: | 2501
|
| 1968: | 3544
|
| 1969: | 4065
|
| Final: | 4584
|
how to read serial numbers...
|
| Electrical |
| Charging system: | generator
|
| Battery volts: | 12
|
| Battery AH: | 40 (gas)
|
| | 96 (diesel)
|
|
