International Harvester 585 Tractors
|
|
Power: 62 hp
Date of manufacture : 1981 - 1985 |
Production |
Manufacturer: | International Harvester
|
Type: | Utility tractor
|
Factory: | Doncaster, England
|
International Harvester 585 Power |
Engine (gross): | 62 hp 46.2 kW
|
Engine (net): | 58.9 hp 43.9 kW
|
PTO (claimed): | 52.7 hp 39.3 kW
|
International Harvester 585 Engine |
Mechanical |
Chassis: | 4x2 2WD
|
| 4x4 MFWD 4WD
|
Differential lock: | rear standard
|
Steering: | power
|
Brakes: | hydraulic wet disc
|
Cab: | Cab standard. Economy and Deluxe cabs available.
|
Transmissions: | 8-speed synchromesh
|
| 16-speed two-speed power shift
|
Hydraulics |
Pump flow: | 12.4 gpm 46.9 lpm
|
Tractor hitch |
Control: | position and draft control
|
Rear lift: | 4400 lbs 1995 kg
|
| 5250 lbs 2381 kg *With optional assistor ram
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Clutch: | hydraulic wet disc
|
Rear RPM: | 540/1000
|
Dimensions & Tires |
Wheelbase: | 85 inches 215 cm
|
Weight: | 6394 to 7188 pounds
|
Front tire: | 7.50-18
|
Rear tire: | 13.6-38
|
Full dimensions and tires ... |
585 Serial Numbers |
Location: | Serial number plate on right front of tractor frame, above the front axle.
|
|
