International Harvester 806 Tractors
 |
|
Power: 105 hp[P]
Date of manufacture : 1963 - 1967 |
| Production |
| Manufacturer: | International Harvester
|
| Type: | Standard-tread tractor
|
| Total built: | 8,052
|
| Original price: | $6,800 (1967)
|
| Variants |
| IH 806: | standard-tread
|
| Farmall 806: | row-crop
|
| International Harvester 806 Power |
| Drawbar (claimed): | 86.6 hp
64.6 kW
|
| PTO (claimed): | 94.93 hp
70.8 kW
|
| International Harvester 806 Engines |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic dry disc
|
| Cab: | Open operator station
|
| Transmissions: | 8-speed unsynchronized
|
| | 16-speed partial power shift
|
| Photos |
| | International Harvester 806 photos... |
| Capacity |
| Fuel: | 42 gal
159.0 L
|
| | 48 gal
181.7 L (LP)
|
| Hydraulic system: | 17 gal
64.3 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 17 gal
64.3 L
|
| Pump flow: | 12 gpm
45.4 lpm
|
| | 3 gpm
11.4 lpm (PTO pump)
|
| Total flow: | 24 gpm
90.8 lpm
|
| Steering flow: | 9 gpm
34.1 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Type: | IH Fast Hitch
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| | 540/1000
|
| Dimensions & Tires |
| Wheelbase: | 91 inches
231 cm
|
| Weight: | 8460 to 9220 pounds
|
| Front tire: | 7.50-20
|
| Rear tire: | 18.4-34
|
| Full dimensions and tires ... |
| 806 Serial Numbers |
| 1963: | 501
|
| 1964: | 1403
|
| 1965: | 3758
|
| 1966: | 5917
|
| 1967: | 7409
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| Charging amps: | 25
|
| Batteries: | 2 (diesel)
|
| | 1 (gas/LP)
|
| Battery volts: | 6 (diesel)
|
| | 12 (gas/LP)
|
| Battery AH: | 170 (diesel)
|
| | 60 (gas/LP)
|
|
